Mechanical |
Dimensions |
(LxWxH) 60 mm x 168 mm x 74 mm (2.3˝ x 6.6˝ x 2.9˝) |
Weight |
133 g (4.7 oz) |
Electrical |
Input Voltage |
5 V ± 5% |
Operating Power |
700 mW; 140 mA (typical) @5V |
Standby Power |
425 mW; 85 mA (typical) @ 5V |
Host System Interfaces |
Multi-interface; includes USB (HID Keyboard, Serial, IBM OEM), RS232 (TTL + 5V, 4 signals), Keyboard Wedge, |
RS-232C (± 12V), IBM RS485 supported via adapter cable |
Environmental |
Operating Temperature |
0°C to 40°C (32°F to 104°F) |
Storage Temperature |
-20°C to 60°C (-4°F to 140°F) |
Humidity |
5% to 95% relative humidity, non-condensing |
Drop |
Designed to withstand 30 drops on concrete from 1.5 m (5’) |
Environmental Sealing |
IP40 |
Light Levels |
0-75,000 Lux (direct sunlight) |
Scan Performance |
Scan Pattern |
Single scan line |
Scan Angle |
Horizontal: 30° |
Print Contrast |
20% minimum reflectance difference |
Pitch, Skew |
60°, 60° |
Decode Capabilities |
Reads standard 1D and GS1 DataBar symbologies |
